Foshan Shunde Dongyuan Gas Appliances Industrial Co., Ltd. Foshan Dongyuan Thermal Technology Co.,Ltd
8 Years
| Ask Lasest Price | |
| Brand Name : | Dongyuan |
| Model Number : | L1PB24-HY |
| Certification : | ISO14001,ISO9001,OHSAS18001 |
| Price : | USD230-250pcs |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability : | 10000pcs per month |
| Delivery Time : | 30days after receiving the deposit |
Wall Mounted Style Wall Hung Gas Boiler For Apartment And Water Heating
Technical data
| Model Number | L1PB16 | LIPB18 | L1PB20 | L1PB24 | L1PB32 | L1PB36 |
| Gas Type | NG/LPG | |||||
| Rated Gas Pressure(Pa) | 2000/2800 | |||||
| Rated Gas Input(kw) | 16 | 18 | 20 | 24 | 32 | 36 |
| Rated Gas Output(kw) | 14.1 | 15.9 | 17.6 | 21.1 | 28.2 | 31.7 |
| Efficiency Under Rated Heat Input(%) | Above88% | |||||
| Power Supply | 20-50HZ | |||||
| Electric Power(W) | 110 | 110 | 110 | 110 | 145 | 145 |
| Temp.Range Of Heating Water(℃) | Radiator:30-80 Floor Heating:30-60 | |||||
| Heating Area(㎡) | 60-120 | 70-140 | 80-160 | 100-200 | 200-300 | 200-300 |
| Lift Of pump(m) | 5 | 5 | 5 | 5 | 7 | 7 |
| Application Water Pressure(Mpa) | 0.1-0.3 | |||||
| Expansion Tank Capacity(L) | 6 | 6 | 6 | 6 | 8 | 8 |
| Preset Pressure Of Expansion Vessel(Mpa) | 0.1 | |||||
| Water Circulation Type | Airtight Forced Circulation | |||||
| △T=25℃ Hot Water Supply(kg/min) | 8 | 9 | 10 | 12 | 16 | 18 |
| △T=30℃ Hot Water Supply(kg/min) | 6.7 | 7.5 | 8.3 | 10 | 13.3 | 15 |
| Temp.Range Of DHW Supply(℃) | 30-60 | |||||
| Applicative Water Pressure(mpa) | 0.03-0.8 | |||||
| The Minimum Starting Flow (L/min) | 2 | |||||
| The Minimum Closed Flow(L/min) | 1.6 | |||||
| Connections(mm) | For Gas&Heating Water Pipes:G3/4 For DHW Pipes:G1/2 | |||||
| Air Input/Exhaust Duct(mm) | φ60/φ100 | |||||
| Sparated Input/Exhaust Duct(optional) | φ80/φ100 | |||||
| The length Of Flue Dust(m) | 1 | |||||
| Noise On Working(DB) | ＜42 | |||||
| Exhaust Type | Forced Exhaust | |||||
| Ignition Type | Integrated Automatic Ignition | |||||
| Temperature Control | Gas Proportional Adjustment | |||||
| Product Dimensions(mm) | 740*400*305 | 855*470*390 | ||||
| Packing Dimensions(mm) | 865*470*385 | 870*495*390 | ||||
| Container(20GP/40GP/40HQ) | 17//357/434 | 166/333/404 | ||||
- Solid chamber structure design reduces combustion noise.
- Multiple automatic protections.
- Gas flow proportional control,provide sable heating temperature.
- Micro-computer control and self-inspection system.
- Proportional controlling of gas flow, and heating with frequency conversion.
- LCD display showing the actual working condition.
- Fashionable flat panel design, easy to operate.
- Water flow and temperature double control, provides stable domestic hot water temperature.
- Proportional controlling of gas flow, and heating with frequency conversion.
- With digital LED display and all working condition is clear.
- With function of heating and domestic hot water to be used freely.
- With design of stable wind resistance, and the boiler works stably even in bad weather.
- With overtime protection when time for constant domestic hot water is more than 60 minutes,and the bath would be more safe.
- With special mode of floor heating as 60℃ limited temperature protection, and be more comfortable.
- With special device of explosion protection to protect the boiler.
- With 20 kinds of safe protection to protect your while family.
-With selectable device of indoor thermostat, the indoor temperature would be set freely and 20% energy saving.
-Popular model to export more than 20 countries.
Features:
- Anti-lock function for pump.
- Water pressure monitor function of heating circulation
- Flame out protection.
- Automatic by pass function for pump and control system.
- Reignition function.
- Self diagnostic function
- Wind pressure safety protection
-Twice Anti freezing function.
- Overheat protection for domestic hot water.
- Defer ignition function.
-Automatic circulation function of pump.
|
|
