High Thermal Efficiency Simple Operation For Radiator And Floor Heating LCD display Home Gas Boiler
Technical data
| Model Number | L1PB16 | LIPB18 | L1PB20 |
| Gas Type | NG/LPG | ||
| Rated Gas Pressure(Pa) | 2000/2800 | ||
| Rated Gas Input(kw) | 16 | 18 | 20 |
| Rated Gas Output(kw) | 14.1 | 15.9 | 17.6 |
| Efficiency Under Rated Heat Input(%) | Above88% | ||
| Power Supply | 20-50HZ | ||
| Electric Power(W) | 110 | 110 | 110 |
| Temp.Range Of Heating Water(℃) | Radiator:30-80 Floor Heating:30-60 | ||
| Heating Area(㎡) | 60-120 | 70-140 | 80-160 |
| Lift Of pump(m) | 5 | 5 | 5 |
| Application Water Pressure(Mpa) | 0.1-0.3 | ||
| Expansion Tank Capacity(L) | 6 | 6 | 6 |
| Preset Pressure Of Expansion Vessel(Mpa) | 0.1 | ||
| Water Circulation Type | Airtight Forced Circulation | ||
| △T=25℃ Hot Water Supply(kg/min) | 8 | 9 | 10 |
| △T=30℃ Hot Water Supply(kg/min) | 6.7 | 7.5 | 8.3 |
| Temp.Range Of DHW Supply(℃) | 30-60 | ||
| Applicative Water Pressure(mpa) | 0.03-0.8 | ||
| The Minimum Starting Flow (L/min) | 2 | ||
| The Minimum Closed Flow(L/min) | 1.6 | ||
| Connections(mm) | For Gas&Heating Water Pipes:G3/4 For DHW Pipes:G1/2 | ||
| Air Input/Exhaust Duct(mm) | φ60/φ100 | ||
| Sparated Input/Exhaust Duct(optional) | φ80/φ100 | ||
| The length Of Flue Dust(m) | 1 | ||
| Noise On Working(DB) | ＜42 | ||
| Exhaust Type | Forced Exhaust | ||
| Ignition Type | Integrated Automatic Ignition | ||
| Temperature Control | Gas Proportional Adjustment | ||
| Product Dimensions(mm) | 740*400*305 | ||
| Packing Dimensions(mm) | 865*470*385 | ||
- Self- diagnostics system. Error will be shown once there is any fault.
- Multiple security devices ensure high safety grade including anti-freezing protection, overheat
protection, by-pass protection, and so on.
- Extra quiet. Noise is less than 55db when working.
-Four section timer.
- Large screen display.
- Forced exhaust.
- Max heating power and max DHW supply can be adjusted separately.
-Inteligent constant temperature control will provide easeful warmth for your rooms and comfortable shower water anytime.
-Thermostat optional
- Microcomputer automatic control, automatic detection of running state.
- Gas flow proportional control, variable frequency and energy- saving heating.
-Ultra-quiet design with air combustion, extremely quiet.
-Green environmental protection,ultra-low emission.
-Touch buttons, big-screen dynamic LCD display, sensitive and comfortable.
- Human man-machine interface,easy operation and maintenance.
-Dynamic fire display, automatic central control data output, intuitive and convenient.
- Stable appearance,classic style, simple and handsome-one shell.
-Multiple security features, automatic return to work status,security no worries.
- Digital precise temperature control system, are free to adjust temperature.
-Integrated design of control system, 120 degree turns over freely, convenient for maintenance.
-Multiple automatic protecting function ensure safety and reliability.
-24H timing switch enable setting on/off with random needs.
-Main heat exchanger with high efficiency and energy-saving enable heating efficiency reach Europe Standard.
-With Aluminum fan and good quality ball bearing ensure low noise while working.
- Advanced pressure sensors technology process monitoring and water pressure displaying, ensure boiler safety.
- Unique remote control system realizing climate compensation function,ensure energy saving.
- With simple operation muti-function human-machine conversation system.
- With efficient, energy saving and high lift water pump ensure boiler low water supplier reliable and comfortable.
-The main parts are come from famous brand supplier which ensure best quality. -Supper bigger LED display with durable touch switch operation.
- With modular structure design,20% thin than normal mode.
-High efficient sealed chamber system ensure sufficient burning and energy saving.
-Muti-period timer,thermostat comfortable, energy-saving gas .
- Digital display system pressure,more precisely.
-Stand-button design, operation is very simple.
- Large LCD blue screen, so that the boiler running at a glance.
- New lid design ,commissioning maintenance is very convenient.
|
|
